Product Overview
The self-propelled scissor lift (self-propelled scissor aerial work platform) is a battery-powered mobile elevating work platform that integrates traveling, lifting, and steering functions. The operator can stand on the platform and independently drive the machine to move forward, reverse, steer, and raise/lower from the platform control box at any working height, without requiring assistance or getting off the platform.
It is widely used for equipment installation and maintenance in building decoration, factories, workshops, warehouses, stations, airports, and similar locations.
Product Parameter
|
Parameter Name |
GTJZ04 |
GTJZ06 |
GTJZ08 |
GTJZ10 |
GTJZ12 |
GTJZ14 |
|
Platform Height (m) |
3.8 |
5.8 |
8 |
10 |
12 |
13.8 |
|
Working Height (m) |
5.8 |
7.8 |
10 |
12 |
14 |
15.8 |
|
Extension Platform Length (m) |
0.6 |
0.9 |
0.9 |
0.9 |
0.9 |
0.9 |
|
Platform Capacity (kg) |
230 |
230 |
230 |
320 |
320 |
230 |
|
Extension Platform Capacity (kg) |
100 |
100 |
100 |
100 |
100 |
100 |
|
Gradeability |
25% |
25% |
25% |
25% |
25% |
25% |
|
Maximum Operating Tilt (°) |
1.5/3 |
1.5/3 |
1.5/3 |
1.5/3 |
1.5/3 |
1.5/3 |
|
Turning Radius (m) |
1.9 |
2.1 |
2.2 |
2.2 |
2.2 |
2.6 |
|
Travel Speed (km/h) |
3.5 |
3.5 |
3.5 |
3.6 |
3.6 |
3.6 |
|
Lifting/Lowering Speed (m/min) |
3-5 |
3-5 |
3-5 |
3-5 |
3-5 |
3-5 |
|
Stowed Length × Width (m) |
1.51*0.76 |
1.82×0.76 |
2.48×1.15 |
2.48×1.15 |
2.48×1.15 |
2.83×1.25 |
|
Stowed Height / Folded Guardrail (m) |
1.91/1.47 |
2.2/1.84 |
2.32/1.82 |
2.45/1.95 |
2.57/2.07 |
2.6/2.1 |
|
Platform Dimensions (m) |
1.37×0.15 |
1.65×0.75 |
2.32×1.13 |
2.32×1.13 |
2.32×1.13 |
2.68×1.13 |
|
Ground Clearance (m) |
0.08/0.02 |
0.08/0.02 |
0.08/0.02 |
0.08/0.02 |
0.08/0.02 |
0.08/0.02 |
|
Drive Wheel Size (mm) |
Φ255×76 |
Φ305×100 |
Φ381×127 |
Φ381×127 |
Φ381×127 |
Φ381×127 |
|
Curb Weight (kg) |
950 |
1500 |
2450 |
2710 |
2880 |
3150 |
|
Lifting Motor Specification |
24V/2.5kw |
24V/3.0kW |
24V/4.5kW |
24V/4.5kW |
24V/4.5kW |
24V/4.5kW |
|
Battery Configuration |
12v×2/80Ah |
12v×2/150Ah |
4×6V/200Ah |
4×6V/200Ah |
4×6V/200Ah |
4×6V/260Ah |
|
Charger Specification |
24V/25A |
24V/30A |
24V/30A |
24V/30A |
24V/30A |
24V/30A |
Product Feature And Application
Features of the self-propelled scissor lift
Self-propelled mobility: Can continuously perform forward, backward, and turning actions at different heights without external power supply or towing equipment.
Stable structure: Maintains a level position during lifting, offering high stability suitable for multi-person operations.
Easy operation: A single operator can control all actions from the platform without extensive training.
Multiple safety protections: Equipped with overload protection, tilt alarm, anti-fall guardrails, emergency descent, hose burst protection valve, and other devices.
Low noise, zero emissions: Electrically driven, producing no harmful gases and low noise, suitable for indoor and environmentally sensitive locations.
Application of the self-propelled scissor lift
1.Warehousing and Logistics: Accessing and organizing high-level racking; installation and maintenance of lighting, monitoring, and fire safety equipment on warehouse ceilings; internal pipeline maintenance. A core piece of equipment in modern smart warehouses.
2.Building Construction and Factory Maintenance: Interior finishing (ceiling, wall, and light installation); plant maintenance (equipment installation/repair, pipeline work, steel structure maintenance); internal work during the mid-to-late stages of building construction.
3.Commercial and Public Facilities: Routine cleaning, light replacement, decorative installation, and signage mounting in shopping centers, airports, stadiums, and convention centers. Their quiet, clean operation is crucial for these environments.
4.Industrial Production: Providing flexible, mobile elevated work platforms for assembly lines in automotive manufacturing, aircraft repair, and large equipment assembly.
5.Specialized Industries: Power facility maintenance (substation equipment); shipbuilding and repair; landscaping (tree trimming); film and television production (lighting and camera positioning).
Product Details
|
|
Wheels Common types include polyurethane solid wheels (for indoor use, protect floors), non-marking tires (good elasticity and leave no traces), and pneumatic/all-terrain tires (for rough outdoor ground, good shock absorption). Typically, some wheels are drive wheels (driven by an electric motor), while the rest are swivel casters (responsible for steering), providing flexible mobility. |
|
|
Battery Primarily uses lead-acid batteries (cost-effective and durable) or lithium-ion batteries (lighter, faster charging, longer lifespan, and no memory effect). Require regular charging to maintain adequate power; even during prolonged storage, periodic maintenance charging is necessary. |
|
|
Scissor Mechanism Consists of multiple sets of high-strength steel arms connected by pins in a scissor configuration, extended or retracted by a hydraulic cylinder. The mechanical structure is highly stable, offers strong load-bearing capacity, and ensures smooth and reliable lifting/lowering. |
|
Ground Working Platform Its interior and underside primarily integrate the drive system (including motors, drive wheels, and steerable wheels), hydraulic power system (pump station, oil tank, and motor), and the control and electrical system (battery, main controller, and tilt sensors). |
 |
Control System Includes the platform control box (main operation interface), chassis control/remote control, the main controller (ECU), and various sensors (such as tilt sensors). |
Certification
After-sales Support
Warranty Policy
2-year warranty on the main structure of the equipment.
1-year warranty on the hydraulic pump, motor, and electrical control system.
24/7 Technical Support
Our technical experts provide round-the-clock online fault diagnosis, repair guidance, and troubleshooting solutions.
Spare Parts Supply
We maintain ample spare parts inventory, ensuring long-term, fast, and cost-effective supply to customers, minimizing your aerial work platform downtime and maintenance costs.
FAQ
Q: What is the first step that must be taken before operating the self-propelled scissor lift?
A: Perform a pre-operation inspection, including checking battery level, tire pressure, hydraulic oil level, and ensuring control devices and safety functions (e.g., emergency stop buttons) are normal.
Q: What should be paid attention to when moving the self-propelled scissor lift at height?
A: The travel speed must be set to low gear. Look in the direction of movement, ensure the path is level and unobstructed, and operate slowly and smoothly.
Q: Can the self-propelled scissor lift be used on uneven or soft ground?
A: Strictly prohibited. It must be used on solid, level ground to prevent tipping. For specific uneven terrain, dedicated rough-terrain models should be selected.
Q: What should the operator do when the self-propelled scissor lift's tilt alarm activates?
A: Immediately stop all movement, slowly lower the platform to its lowest position, and then move the equipment to a level, solid surface before resuming work.
Q: Can an operator on the platform lean against or reach over the guardrails?
A: Absolutely prohibited. The operator's center of gravity must always remain inside the platform guardrails, and the anchorage point for a safety lanyard should be used correctly.
Q: Under what circumstances is the emergency descent device used, and how is it operated?
A: It is used when the main power fails or the hydraulic system malfunctions, preventing normal descent. Operation typically involves turning or pulling a manual pump/relief valve; consult the equipment manual for specific instructions.
Q: What are the basic contents of routine maintenance?
A: Mainly include: keeping the self-propelled scissor lift clean (especially hydraulic cylinders and guide pins), checking the structure for damage or cracks, inspecting tire wear, and ensuring the battery is adequately charged.
